Genie S-85 XC 4WD

Genie S-85 XC 4WD Key Facts

  • Max. Working Height Max. Working Height: 27.91m
  • Max. Horizontal Outreach Max. Horizontal Outreach: 22.71m
  • Travel Width Travel Width: 2.5m
  • Lift Capacity Lift Capacity: 454kg
  • Weight Weight: 17,917kg
  • Power Source Power Source: Diesel

NEED SOME HELP?

Fill in your details below and a member of our team will get back to you shortly. Need some help? Call us on 01480 891251 or email sales@accessplatforms.co.uk

Genie S-85 XC 4WD Key Facts

  • Industry-leading lift capacity of 454kg (300kg unrestricted)
  • Patented axle technology for superb rough terrain
  • Fast boom lift speed and 360˚ continuous turntable rotation
  • Good in tight spaces thanks to minimal tail swing design
  • Stage IIIA and V Engine
  • Lift Tool™ Work Tray

The Genie S-85 XC provides a 27.9m maximum working height and excellent horizontal reach of 22.7m, with a lift capacity of 454kg - sufficient for two people with tools. It provides two safe working loads – up to 454kg with a restricted envelope or up to 300kg with unrestricted operation, which allows up to three people with tools to work on the platform.

Great drive performance is assured by positive traction control and automatic axle adjustment and the Genie S-85 XC features exclusive virtual pivot boom design, which maintains the weight of the boom over the chassis’ centre of gravity as it elevates. This keeps the overall weight of the machine down by reducing the amount of counterweight required, making it ideal for use on sensitive terrain. Also available with reduced working height as the Genie S-80 XC 4WD.

Specifications

More Information
Max. Working Height 27.91m
Max. Horizontal Outreach 22.71m
Lift Capacity 454kg
Power Source Diesel
Weight 17,917kg
Travel Width 2.5m
Lifting Mechanism Telescopic Boom
Chassis Type RT Diesel Self propelled
