Genie SX-105 XC 4WD

Genie SX-105 XC 4WD Key Facts

  • Max. Working Height Max. Working Height: 34m
  • Max. Horizontal Outreach Max. Horizontal Outreach: 24.38m
  • Travel Width Travel Width: 2.49m
  • Lift Capacity Lift Capacity: 454kg
  • Weight Weight: 19,300kg
  • Power Source Power Source: Diesel


Fill in your details below and a member of our team will get back to you shortly. Need some help? Call us on 01480 891251 or email

Genie SX-105 XC 4WD Key Facts

  • Industry-leading lift capacity of 454kg (300kg unrestricted)
  • Extendable axles for additional stability on rough terrain
  • Platform rotation and self-levelling as standard
  • 4WD and 4W steer for rough terrain performance
  • Perfect for areas with limited access in construction and industrial applications
  • Stage IIIA and V Engine
  • Lift Tool™ Work Tray

The Genie SX-105 XC provides a 34m max. working height and outreach of up to 24.4m, offering a great working envelope with a lifting capacity of up to 454kg and provides two safe working loads – 454kg with a restricted envelope or up to 300kg with unrestricted operation, which allows up to three people with tools to work on the platform.

The Genie SX-105 XC 4WD booms are also designed for productivity with the traction and drive speed you need to get around the job site and to the work area. It has a telescoping job which delivers 135° up/down rotation and can be driven when working at full height. The new mini XChassis axle feature means axles can be extended for additional stability.


More Information
Max. Working Height 34m
Max. Horizontal Outreach 24.38m
Lift Capacity 454kg
Power Source Diesel
Weight 19,300kg
Travel Width 2.49m
Lifting Mechanism Telescopic Boom
Chassis Type RT Diesel Self propelled
